Description
* Impulse and frequency multiplier for use with incremental encoders and sensors
* Frequency range 1 MHz (input and output), programmable index pulse output
* Universal inputs for incremental encoder signals A, B, Z or A, /A, B, /B, Z, /Z with either TTL level or RS422 format or HTL level
* Also suitable for optical sensor, proximity switches or NAMUR switches
Specification Detail
Module Type: Frequency Transducer
Input Type: Frequency Pulse
Output Type: Frequency Pulse
Input Frequency: 1 MHz
Operating Voltage Min.: 9 V
Operating Voltage Max.: 24 V
Channels: 3
Current Consumption: 70 mA
Termination Type: Screw Terminal
Mounting Type: DIN Rail Mount
Cross-Section: 1.5 mm²
Protection Rating: IP20
